Ultra-High-End Workstations

BIS ZU VIER 24-KERN PROZESSOREN UND 8 GRAFIKKARTEN

Mit bis zu acht High-End NVIDIA® Quadro Grafikkarten stehen Ihnen bis zu 384 GB Framebuffer zur Verfügung. Digitales Prototyping, 3D-Animationen und Visual FX fordern genauso, wie aufwändige Analysen in den Bereichen GEO und GIS, extrem hohe Leistungen von den verbauten Intel-Prozessoren sowie den GPUs. Mit dieser Workstation-Serie sind Sie auf der sicheren Seite und können mit ihr Rechenleistungen abrufen, die zuvor nur in Rechenzentren verfügbar waren.

Highlights

•    bis zu vier Prozessoren mit 24 Kernen

•    bis zu 12TB DDR4 ECC RAM möglich

•    bis zu acht High-End NVIDIA Quadro Grafikkarten

•    optional QuadroSnyc-Modul für SyncGenlock/Framelock

•    optional Intel® X550 Netzwerkadapter für die schnelle Anbindung

•    optional InfiBand - die serielle Hochgeschwindigkeitsübertragungstechnik

•    Bis zu 4608 CUDA Prozessoren pro GPU

Durch die Herstellung im BTO-Prinzip kann das System für viele Anwendungsgebiete und Erfordernisse der eingesetzten Software nach Kundenwunsch angepasst werden.

ProGraphics Workstation R8880S - Dual RTX 6000 Sync

3U Rack - black (132x437x647mm) / 8x 3.5" Hot-Swap SAS/SATA (6Gb/s) + 2x 5.25" Drive Bays + 1x Slim DVD / 800W - Redundant - 80PLUS Titanium / Dual socket P (LGA 3647) / Intel® C621 Chipset / 2x Intel® Xeon® Gold 6244 - 8x 3.6GHz - 150W / 12x 32GB DDR4-2933 ECC reg. (total 384GB) / Dual-Port GigE - 2x RJ45 (onboard) + 1x RJ45 dedicated IPMI / Remote Management: IPMI 2.0 / Dual Port 10GbE - NVIDIA ConnectX-4 Lx EN - SFP+ / Single Port EDR / FDR / QDR / DDR / SDR InfiniBand 100GbE Adapter - ConnectX®-5 VPI / 2x Nvidia Quadro RTX6000 - 24GB - 4x DP 1.4 + VirtualLink + Nvidia Quadro Sync II / 2.0 TB SSD - TLC - M.2 2280 - MVMe / Microsoft© Windows 10 Pro / Guarantee: 36 months bring-in (Advanced Replacement) - optional: 36/60 month on-site service NBD Key Features 1. Processor 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors 2. System Memory Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz in 16 DIMMS 3. On-Board Devices 10 SATA 3.0 6Gbps (Software Raid 0,1,5 & 10) Dual LAN with 1GbE with Intel® X722 + Marvell 88E1512 ASPEED AST2500 (IPMI) 4. Expansion Slots 3 PCI-E 3.0 x16 4 PCI-E 3.0 x8 M.2 Interface: 2 PCI-E 4.0 x4 (Software RAID 0) 5. Input / Output 7 USB 3.0 ports (4 rear + 2 headers + 1 Type A) 1 VGA port 1 COM Ports (1 rear) 1 TPM Header

Preis auf Anfrage

ProGraphics Workstation T9660S - RTX 5000

Tower - Rack - black (452x178x647mm) / 6x 3.5" Hot-Swap SAS/SATA (6Gb/s) / 1200W - 80PLUS Platinum redudant / Single Socket sWRX8/SP3 - AMD Ryzen™ Threadripper™ PRO 3000WX Series / Chipset AMD WRX80 / 1x AMD Ryzen ThreadRipper PRO 3995WX - 64x 2.7GHz - 280W / 8x 16GB DDR4-3200 ECC reg. (total 128GB) / Single LAN via Marvell AQC113C 10Gb controller + Single LAN via via Intel® i210AT controller (shared with IPMI) / Remote Management: IPMI 2.0 / Nvidia Quadro RTX5000 - 16GB - 4x DP + 1x VirtualLink / OS: 1.0 TB TLC M.2 2280 - PCI-E 3.0 x4 - NVMe + 2x 2.0 TB HDD - SATA 6Gb/s - 3.5" - 256-Bit-AES / Microsoft® Windows 10 Pro, 64-bit / Guarantee: 36 months bring-in (Advanced Replacement) - optional: 36/60 month on-site service NBD Key Features 1.Processor AMD Ryzen™ Threadripper™ PRO 3000WX Series Processor, up to 64 Cores 2.System Memory Up to 256GB Unbuffered non-ECC UDIMM/ 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMS 3. On-Board Devices 4 SATA 3.0 6Gbps (Software Raid 0,1,5 & 10) 1 10GBase-T LAN port1 GbE LAN port (shared with IPMI) ASPEED AST2600 BMC graphics (VGA - IPMI) 4.Expansion Slots 6 PCI-E 4.0 x16 slotsM.2 Interface: 4 PCI-E 4.0 x4 (Software RAID 0,1,5,10) 5. Input / Output 1 USB 3.2 Gen2x2 port (Type C, 20Gbps)5 USB 3.2 Gen2 ports (4 type A + 1 front type C header)5 USB 3.2 Gen1 ports (3 type A + 2 via header)2 USB 2.0 ports via header 1 COM port (rear)1 TPM 2.0 header7.1 Channel HD Audio

Preis auf Anfrage

ProGraphics Workstation R8880S - RTX 6000 Sync

3U Rack - black (132x437x647mm) / 8x 3.5" Hot-Swap SAS/SATA (6Gb/s) + 2x 5.25" Drive Bays + 1x Slim DVD / 800W - Redundant - 80PLUS Titanium / Dual socket P (LGA 3647) / Intel® C621 Chipset / 2x Intel® Xeon® Gold 6244 - 8x 3.6GHz - 150W / 12x 32GB DDR4-2933 ECC reg. (total 384GB) / Dual-Port GigE - 2x RJ45 (onboard) + 1x RJ45 dedicated IPMI / Remote Management: IPMI 2.0 / Dual Port 10GbE - NVIDIA ConnectX-4 Lx EN - SFP+ / Single Port EDR / FDR / QDR / DDR / SDR InfiniBand 100GbE Adapter - ConnectX®-5 VPI / Nvidia Quadro RTX6000 - 24GB - 4x DP 1.4 + VirtualLink + Nvidia Quadro Sync II / 2.0 TB SSD - TLC - M.2 2280 - MVMe / Microsoft© Windows 10 Pro / Guarantee: 36 months bring-in (Advanced Replacement) - optional: 36/60 month on-site service NBD Key Features 1. Processor 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors 2. System Memory Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz in 16 DIMMS 3. On-Board Devices 10 SATA 3.0 6Gbps (Software Raid 0,1,5 & 10) Dual LAN with 1GbE with Intel® X722 + Marvell 88E1512 ASPEED AST2500 (IPMI) 4. Expansion Slots 3 PCI-E 3.0 x16 4 PCI-E 3.0 x8 M.2 Interface: 2 PCI-E 4.0 x4 (Software RAID 0) 5. Input / Output 7 USB 3.0 ports (4 rear + 2 headers + 1 Type A) 1 VGA port 1 COM Ports (1 rear) 1 TPM Header

Preis auf Anfrage

ProGraphics Workstation R7990S - RTX A6000

2U Rack - black (89x437x780mm) / 24x 2.5" Hot-Swap SAS2/SATA (6Gb/s) - 4x Hybrid ports with NVMe support / 1600W - 80PLUS Titanium / QUAD socket P (LGA 3647) / Intel® C621 Chipset / 4x Intel® Xeon® Platinum 8268 - 24x 2.9GHz - 205W / 16x 64GB DDR4-3200 ECC reg. (total 1024GB) / Dual Port 10GbE Network Adapter SFP+ - IPMI / NVIDIA RTX A6000 - 48GB - 4x DP / OS: 1024 GB SSD TLC - M.2 2280 - NVMe / DATA: 2x 3.84 TB SSD TLC - M.2 2280 - NVMe / Operating System: optional / Guarantee: 36 months bring-in (Advanced Replacement) - optional: 36/60 month on-site service NBD Key Features 1.Processor Quad Socket P (LGA 3647) support - 2nd Gen Intel® Xeon® Scalable processors 2.System Memory up to 12TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel® Optane™ DCPMM in 48 DIMMs 3. On-Board Devices 4 GbE LAN ports via AOC-2UR66-i4G1 dedicated IPMI LAN port 4.Expansion Slots 5 PCI-E 3.0 x8 slots,6 PCI-E 3.0 x16 slots 5. Input / Output 4 RJ45 GbE LAN ports 1 RJ45 Dedicated IPMI LAN port 2 USB 3.0 ports (rear) 1 VGA Connector 1 COM port (rear)

Preis auf Anfrage

ProGraphics Workstation R7990S - RTX A6000

2U Rack - black (89x437x780mm) / 24x 2.5" Hot-Swap SAS2/SATA (6Gb/s) - 4x Hybrid ports with NVMe support / 1600W - 80PLUS Titanium / QUAD socket P (LGA 3647) / Intel® C621 Chipset / 4x Intel® Xeon® Gold 6242 - 16x 2.8GHz - 150W / 16x 64GB DDR4-3200 ECC reg. (total 1024GB) / Dual Port 10GbE Network Adapter SFP+ - IPMI / NVIDIA RTX A6000 - 48GB - 4x DP / OS: 1024 GB SSD TLC - M.2 2280 - NVMe / DATA: 2x 3.84 TB SSD TLC - M.2 2280 - NVMe / Operating System: optional / Guarantee: 36 months bring-in (Advanced Replacement) - optional: 36/60 month on-site service NBD Key Features 1.Processor Quad Socket P (LGA 3647) support - 2nd Gen Intel® Xeon® Scalable processors 2.System Memory up to 12TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel® Optane™ DCPMM in 48 DIMMs 3. On-Board Devices 4 GbE LAN ports via AOC-2UR66-i4G1 dedicated IPMI LAN port 4.Expansion Slots 5 PCI-E 3.0 x8 slots,6 PCI-E 3.0 x16 slots 5. Input / Output 4 RJ45 GbE LAN ports 1 RJ45 Dedicated IPMI LAN port 2 USB 3.0 ports (rear) 1 VGA Connector 1 COM port (rear)

Preis auf Anfrage
